The HDF-South was much more complex than the original HDF-North, consisting of a very deep field centered on the quasar in the smaller field of view of the STIS CCD camera (and quasar spectra taken with the spectrographic mode of STIS), plus parallel deep WFPC2 and NICMOS images. Fairly deep images were also taken with STIS superimposed on the deep NICMOS image, with similarly deep parallel images in NICMOS and WFPC2. Finally, shallower Flanking Fields were taken with WFPC2 around and between the STIS, WFPC2, and NICMOS deep fields, and parallel images of similar depth in STIS and NICMOS were taken simultaneously, such that the entire HDF-South consisted of ~30+ fields imaged in 3 cameras across optical and infrared wavelengths, as well as quasar spectra. The STIS Deep Field with quasar in the center is near the top arrow. The NICMOS Deep Field
is at lower left, and WFPC2 Deep Field is at lower right. STIS images were also taken
of the NICMOS Deep Field at lower left. The extreme lower left image was the resulting NICMOS parallel, and the image at bottom center was the resulting WFPC2 parallel, all of medium depth. All the other images were shallower WFPC2 images and their associated STIS
and NICMOS parallels. Credit: NASA, ESA, and Richard Hook (STECF)
